MultiPlus 48/2000/25-32 230V VE.Bus Victron Energy
  • MultiPlus 48/2000/25-32 230V VE.Bus Victron Energy
  • MultiPlus 48/2000/25-32 230V VE.Bus Victron Energy
  • MultiPlus 48/2000/25-32 230V VE.Bus Victron Energy

Inverter/charger Victron Energy MultiPlus 48/2000/25-32 230V VE.Bus, 48 V, 2000 VA

€688 Save €104
€584 Tax included

€487 Tax excluded

MultiPlus 48/2000/25-32 230V VE.Bus is an inverter/charger that combines a pure sine-wave inverter and an adaptive charger for 48 V batteries in a single housing. It delivers 1600 W of continuous power and charges batteries at up to 25 A; PowerAssist technology supplements the power of the grid or generator, and units can operate in parallel or in three-phase.

Reference PMP482200000

Victron Energy commercial warranty: 5 years for defects in materials and workmanship, handled through us as the seller. In addition to the legal guarantee. Conditions

Your legal guarantee rights

Legal guarantee

EU harmonised notice on the legal guarantee of conformity

More information: europa.eu/youreurope/guarantees
Open the notice at full size

MultiPlus 48/2000/25-32 230V VE.Bus - 48 V inverter/charger with PowerAssist

MultiPlus 48/2000/25-32 230V VE.Bus is an inverter/charger that combines a pure sine-wave inverter and an adaptive charger for 48 V batteries in a single housing. It delivers 1600 W of continuous power and charges batteries at up to 25 A; PowerAssist technology supplements the power of the grid or generator, and units can operate in parallel or in three-phase.

Key features:

  • Battery voltage: 48 V (38-66 V)
  • Continuous power: 1600 W / 2000 VA at 25 °C, peak 3500 W
  • Charging current: 25 A, adaptive 4-stage algorithm
  • Transfer relay: 32 A
  • Maximum efficiency: 95%
  • No-load consumption: 10 W, only 3 W in Search mode

As its name suggests, the Multiplus is a combination of an inverter and a charger in an elegant package. Its many features include a pure sine-wave inverter, adjustable charging, PowerAssist hybrid technology, and features for integration with multi-unit systems.

Technical specifications

Nominal battery voltage48 V
PowerControlYes
PowerAssistYes
Parallel operationYes
Three-phase operationYes
Number of AC inputs1
Transfer switch rated current32 A
DC input voltage range38 … 66 VDC
AC output voltage230 VAC
AC output frequency50 Hz
Continuous output power at 25 °C (VA)2000 VA
Continuous output power at 25 °C (W)1600 W
Continuous output power at 40 °C1400 W
Continuous output power at 65 °C1000 W
Peak power3500 W
Maximum efficiency95 %
No-load consumption10 W
No-load consumption in search mode3 W
AC input voltage range187 … 265 VAC
AC input frequency range45 … 65 Hz
Charge voltage in absorption57.6 VDC
Float charge voltage55.2 VDC
Storage mode charge voltage52.8 VDC
Charging algorithmAdaptive, 4-stage
Maximum battery charge current25 A
Temperature sensorIncluded
Number of AC outputs1
Programmable relayAC ratings: 230 V / 4 A, DC ratings: 4 A up to 35 VDC and 1 A up to 60 VDC
ProtectionsOutput short circuit, Overload, High battery voltage, Low battery voltage, Over-temperature, AC voltage at inverter output, Excessive DC ripple
Communication portVE.Bus
Remote control terminalOn / Off
Programmable via DIP switchesYes
Programmable by computerYes
Operating temperature range-40 … 65 °C
Fan-assisted coolingYes
Maximum humidity95 %
Maximum altitude2000 m
AC connection terminalsScrew terminals
Battery connection terminalsM8 bolts
Remote terminal typeTwo-pole screw terminal
Relay terminalThree-pole screw terminal
VE.Bus terminal typeTwo RJ45 terminals
MaterialSteel
ColourBlue (RAL 5012)
Ingress protectionIP21
Weight15.5 kg
Height506 mm
Width236 mm
Depth147 mm
SafetyEN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1
Emission and immunityEN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Automotive directiveECE R10-4

Data sheet

Reference
PMP482200000
EAN13
8719076049470
Brand
Victron Energy
Product type
Inverter/charger
Inverter type
Inverter/charger
Phases
Single-phase
Power class
1-2 kW
Continuous output power (VA, 25 °C)
2000 VA
Continuous output power (W, 25 °C)
1600 W
Peak power
3500 W
Maximum efficiency
95 %
Zero-load power
10 W
Output waveform
Pure sine wave
Battery voltage
48 V
DC input voltage range
38-66 V
Max. charge current
25 A
AC output voltage
230 V
Output frequency
50 Hz
AC input voltage range
187-265 V
Max. AC input current
32 A
Parallel operation
Yes
Communication interfaces
VE.Bus
Programmable relay
Yes
Protections
Output short-circuit, overload, overtemperature, high battery voltage, low battery voltage, excessive DC ripple, AC voltage on output
Dimensions (H x W x D)
506 x 236 x 147 mm
Weight
15.5 kg
Ingress protection (IP)
IP21
Operating temperature
-40 ... 65 °C
Max. relative humidity
95 %
Colour
Blue
Material
Steel
Standards and compliance
EN-IEC 60335-1, ECE R10-4, EN 55014-1, EN 55014-2

We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the attached datasheet.
