€331 Tax excluded
Orion 110/24-15A (360W) is a galvanically isolated DC-DC converter that turns a 110 V DC input, within a 60-140 V range, into a stable 24 V output at 360 W. It has built-in protection against short circuit, overheating, reverse polarity and overvoltage, with 400 V rms isolation between input and output.
Victron Energy commercial warranty: 5 years for defects in materials and workmanship, handled through us as the seller. In addition to the legal guarantee. Conditions
Orion 110/24-15A (360W) is a galvanically isolated DC-DC converter that turns a 110 V DC input, within a 60-140 V range, into a stable 24 V output at 360 W. It has built-in protection against short circuit, overheating, reverse polarity and overvoltage, with 400 V rms isolation between input and output.
| Input voltage range | 60 … 140 V |
|---|---|
| Output voltage | 24 V |
| Output voltage stability | 2 % |
| Output voltage tolerance | 3 % |
| Output voltage noise | 50 mVrms |
| Continuous output current | 15 A |
| Power rating | 360 W |
| Off-load current | 25 mA |
| Maximum efficiency | 85 |
| Fan-assisted cooling | Yes |
| Galvanic isolation | Yes |
| Protections | Over temperature, Overcurrent, Overvoltage, Battery reverse polarity (fuse) |
| Isolation | 400 Vrms |
| Operating temperature range | -20 … 40 °C |
| Maximum humidity | 95 % |
| DC connection terminals | Faston tab 6.3 mm |
| Colour | Grey |
| Material | Anodized aluminium |
| Weight | 1.4 kg |
| Height | 82 mm |
| Width | 132 mm |
| Depth | 190 mm |
| Safety | EN 60950 |
| Emission | EN 55014-1, EN-IEC 61000-6-3 |
| Immunity | EN 55014-2, EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the attached datasheet.
