€520 Tax excluded
Specifically designed for RV and caravan users, this compact battery features CAN and LIN communication for seamless integration with vehicles or backup power inverters. Equipped with all essential safety features, it is highly recommended for advanced applications that support CAN/LIN communication, ensuring optimal performance.
| Rated voltage | 12 V |
| Capacity @ 0.5C 25°C | 106 Ah |
| Cells configuration | 4S1P |
| Nominal voltage | 12.8 V |
| Max voltage | 14.6 V |
| Min voltage | 11.2 V |
| Min voltage - cut off | 10 V |
| Charge voltage | 14.2V-14.6 V |
| Energy | 1356 Wh |
| Max continuous charging current | 100 A |
| Max continuous discharge current | 100 A |
| Peak current (10 seconds) - charge/discharge | 200 A |
| Operating temperature charge | -20°C ~ 55°C |
| Operating temperature discharge | -20°C ~ 55°C |
| Storage temperature (short term) | -20°C ~ 60°C |
| Storage temperature (long term) | 0°C ~ 35°C |
| SoC Display Solution | LEDs or LCD or Mobile App |
| Communication | CAN, LIN, Bluetooth |
| Expected lifetime | 6000 cycles @25°C |
| Dimensions | 278 x 175 x 190 mm (DIN H6/LN3) |
| Weight | 11 kg |
| Case material | PC/ABS NH-1015 |
| IP protection | IP65 |
| Cell type | Prismatic |
| Cell Chemistry | LiFePO4 |
We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the manufacturer’s datasheet.
Compatibility is calculated automatically from the manufacturers’ technical data and is for information only. For complex systems, we recommend having the configuration checked by a consultant before ordering. Details in the Terms and conditions
