Skylla-IP65 24/35(1+1) 120-240V - Waterproof IP65 battery charger 24V 35A
Skylla-IP65 24/35(1+1) 120-240V is a 24 V, 35 A battery charger with a waterproof IP65 enclosure and a universal 90-265 V input that keeps full output power on any grid. The adaptive 7-stage algorithm includes a dedicated Li-ion profile. It has one full-rated output plus an isolated 3 A starter battery output. It suits marine, mobile and industrial applications exposed to heat, humidity and salt air.
Main features:
- Battery voltage: 24 V
- Charge current: 35 A
- Charge outputs: 1 main + 1 isolated 3 A
- Charge algorithm: adaptive 7-stage, Li-ion profile
- Protection rating: IP65, epoxy powder-coated steel case
- Interface: VE.Can (NMEA 2000), LCD display, synchronised parallel operation
A powerful, waterproof and intelligent battery charger with a 7-stage adaptive charge algorithm, suitable for a wide range of battery types and chemistries featuring a dedicated Lithium-ion charge algorithm.
The wide range universal input voltage adds flexibility to the installation, the charger will maintain its full output power no matter where it is located in the world.
The IP65 rating makes this charger especially suitable for marine, mobile, and industrial applications and it can withstand the rigors of an adverse environment: heat, humidity and salt air.
Both models are available in two versions:
- 3 full rated outputs
- 1 full rated output together with an isolated 3A trickle charge output for a starter battery
Technical specifications
| Nominal battery voltage | 24 V |
|---|
| Nominal charge current | 35 A |
|---|
| AC input voltage | 120V or 230V |
|---|
| AC input voltage range | 90 … 265 V |
|---|
| AC input voltage (class) | 120 V - 240 V |
|---|
| Maximum AC input current (2) | 12 A |
|---|
| AC input frequency range | 45 … 65 Hz |
|---|
| Number of charge outputs | 2 |
|---|
| Power factor | 0.98 |
|---|
| Absorption charge voltage | 28.8 V |
|---|
| Float charge voltage | 27.6 V |
|---|
| Storage charge voltage | 26.4 V |
|---|
| Number of full-current outputs | 1 |
|---|
| Low current output | Yes |
|---|
| Starter battery charge current | 3 A |
|---|
| Charge algorithm | Adaptive, 7-stage |
|---|
| Recommended battery capacity | 150 … 350 Ah |
|---|
| Charge algorithm (lithium) | Three stage, with on-off control or CAN-bus control |
|---|
| Temperature sensor | Included |
|---|
| Programmable | Yes |
|---|
| Can be used as power supply | Yes |
|---|
| CAN port | VE.Can, two RJ45 connectors, NMEA2000 protocol, not isolated |
|---|
| Parallel operation | Yes, with VE.Can |
|---|
| Programmable relay | DPST AC rating: 240VAC / 4A, DC rating: 4A up to 35VDC, 1A up to 60VDC |
|---|
| Forced cooling | Yes |
|---|
| Protections | Output short-circuit, Over temperature, Battery reverse polarity (fuse) |
|---|
| Operating temperature range | -20 … 60 °C |
|---|
| Maximum humidity | 95 % |
|---|
| AC connection terminals | screw-clamp 6 mm² (AWG 10) |
|---|
| Battery connection terminals | M6 bolts |
|---|
| Material | Steel |
|---|
| Colour | Blue (RAL 5012) |
|---|
| Protection category | IP65 |
|---|
| Weight | 6 kg |
|---|
| Height | 401 mm |
|---|
| Width | 265 mm |
|---|
| Depth | 151 mm |
|---|
| Safety | EN-IEC 60335-1, EN-IEC 60335-2-29 |
|---|
| Emission | EN 55014-1, EN-IEC 61000-3-2, EN-IEC 61000-6-3 |
|---|
| Immunity | EN 55014-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2 |
|---|
