Cable kit Pylontech 2 x 2 m, 25 mm², with RJ45 communication, US5000 External Cable Kit

Pylontech US5000 External Cable Kit - 2 x 2 m, 25 mm² cable kit with RJ45 communication

Pylontech US5000 External Cable Kit is the external cable kit for connecting a group of Pylontech US5000 batteries to the inverter: two 2000 mm power cables (25 mm²) and two 3000 mm RJ45 communication cables. The cables are not included in the battery box.

Main features:

• Power cables: 2 x 2000 mm, 25 mm²
• Current: 100 A continuous, 120 A peak
• Communication cables: 2 x RJ45, 3000 mm
• Intended for: Pylontech US5000 to inverter
• Max. external length: less than 3 m

The two power cables (positive and negative) are 2000 mm long with a 25 mm² cross-section; one pair carries 100 A continuously and 120 A at peak. A group whose current exceeds 120 A needs two pairs of power cables. External cables must be shorter than 3 metres.

The two RJ45 cables are the WI0SCAN30RJ1 (blue mark, pins 1-3 not connected), for the link between the battery master module and the inverter or hub, and the WI0SCAN35RJ3 (silver mark, pin to pin), for paralleling the master modules of several groups. The manufacturer states that the kit is in a box separate from the battery box and is used for each energy storage system.
