LiFePO4 Battery 12,8V/100Ah NG Victron Energy

12.8 V
€748 Save €113
€635 Tax included

€529 Tax excluded

LiFePO4 12,8V/100Ah NG is a lithium iron phosphate battery module from the NG series for 12 V systems, with read-out of individual cell voltages and temperatures and an IP65 housing for bracket or strap mounting. It works with a Lynx Smart BMS NG, purchased separately, and is intended for energy storage in off-grid, residential and marine systems.

Reference BAT512110620

Victron Energy commercial warranty: 3 years for defects in materials and workmanship, handled through us as the seller. In addition to the legal guarantee. Conditions

Your legal guarantee rights

Legal guarantee

EU harmonised notice on the legal guarantee of conformity

More information: europa.eu/youreurope/guarantees
Open the notice at full size

LiFePO4 12,8V/100Ah NG - 12V LiFePO4 battery for external BMS

LiFePO4 12,8V/100Ah NG is a lithium iron phosphate battery module from the NG series for 12 V systems, with read-out of individual cell voltages and temperatures and an IP65 housing for bracket or strap mounting. It works with a Lynx Smart BMS NG, purchased separately, and is intended for energy storage in off-grid, residential and marine systems.

Main features:

  • Voltage, capacity, energy: 12.8 V, 100 Ah, 1,280 Wh
  • Cycle life: 2,500 at 80% DoD, 5,000 at 50% DoD
  • Discharge current: 100 A continuous, 200 A pulse
  • Charge current: 100 A continuous
  • Required BMS: Lynx Smart BMS NG, purchased separately
  • Monitoring and updates: VictronConnect, GX device and VRM, via the BMS

Building upon the success of our Lithium Smart Series, the NG (Next Generation) series incorporates significant enhancements.

Highlights:

  • Multiple improvements including added read-out of cell voltages and temperatures;
  • Maximum single bank size increased to 385kWh;
  • Modules available in 12, 24 and 48V;
  • Protection class IP65;
  • Bracket mounting and strap mounting.

Tailored for those seeking advanced and reliable energy storage, the Lithium NG series marks a pivotal advancement in our product lineup, ready to meet the demands of tomorrow.

Technical specifications

Nominal battery voltage12.8 V
Nominal battery voltage (class)12
Nominal battery capacity100 Ah
Nominal energy1280 Wh
Capacity loss1 %
Energy loss1 %
Efficiency92 %
ChemistryLithium Iron Phosphate (LiFePO4 or LFP)
Cycle design life at 80 % DoD2500 cycles
Cycle design life at 70 % DoD3000 cycles
Cycle design life at 50 % DoD5000 cycles
Maximum continuous discharge current100 A
Maximum pulse discharge current200 A
End-of-discharge voltage11.2 V
Internal resistance2 mΩ
Self-discharge rate3 %
Float charge voltage13.5 V
Maximum continuous charge current100 A
Maximum pulse charge current200 A
Storage temperature range-45 … 70 °C
Maximum humidity95 %
Requires external BMS1
BMS included0
BMSLynx Smart BMS NG 500A / 1000A (M10 busbars), must be purchased separately
Cell monitoringCell voltages and temperatures, battery current
BMS cable50 cm male and female cable with M8 circular connector with high-speed digital communication
Alarm functionPre-alarm contact on BMS
BluetoothIn the BMS
Maximum number of batteries per BMS50 (384kWh per BMS) (Up to 5 BMS-es can be paralleled)
Firmware updatesBattery firmware automatically updated by BMS
RepairableYes (cover can be removed with screws)
Battery terminalsM8 threaded inserts
MaterialABS
ColourBlue (RAL 5012)
Protection categoryIP65
Mounting methodStrap or mounting brackets
Mounting orientationThe lithium battery can be mounted upright and on its side, but not with the battery terminals facing down
Weight9 kg
Height235 mm
Width197 mm
Depth160 mm
Safety (cells)IEC 62619, UL 1973, UL 9540A
Safety (battery)IEC 62619 (pending), UL 2054
EMCEN-IEC 61000-6-2, EN-IEC 61000-6-3
Automotive standardECE R10-6
Performance standardIEC 62620

Data sheet

Reference
BAT512110620
EAN13
8719076058892
Brand
Victron Energy
Product type
Battery
Battery chemistry
LiFePO4 (lithium iron phosphate)
Battery voltage
12 V
Nominal voltage (exact)
12.8 V
Nominal capacity
100 Ah
Capacity class
1-2.5 kWh
Nominal energy
1.28 kWh
Cycle life (cycles at 80 % DoD)
2500 cycles
Max. continuous discharge current
100 A
Built-in BMS
No
Max. charge current
100 A
Dimensions (H x W x D)
235 x 197 x 160 mm
Weight
9 kg
Ingress protection (IP)
IP65
Max. relative humidity
95 %
Colour
Blue
Material
ABS plastic
Standards and compliance
UL 2054, ECE R10-6, EN-IEC 61000-6-2, EN-IEC 61000-6-3

We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the attached datasheet.
