Multi RS 48/6000/100-50 230V Victron Energy
  • Multi RS 48/6000/100-50 230V Victron Energy
  • Multi RS 48/6000/100-50 230V Victron Energy
  • Multi RS 48/6000/100-50 230V Victron Energy
  • Multi RS 48/6000/100-50 230V Victron Energy
  • Multi RS 48/6000/100-50 230V Victron Energy

Inverter/charger Victron Energy Multi RS 48/6000/100-50 230V, 6 kVA

€1,593 Save €239
€1,354 Tax included

€1,128 Tax excluded

Multi RS 48/6000/100-50 230V is a lightweight 48 V, 6 kVA high-frequency inverter/charger for stationary and mobile applications, the variant of the Multi RS Solar without integrated solar chargers. It supports Dynamic ESS, can be combined with another solar inverter, and all parameters are monitored on the built-in display or in the VictronConnect app.

Reference PMR482604000

Victron Energy commercial warranty: 5 years for defects in materials and workmanship, handled through us as the seller. In addition to the legal guarantee. Conditions

Your legal guarantee rights

Legal guarantee

EU harmonised notice on the legal guarantee of conformity

More information: europa.eu/youreurope/guarantees
Open the notice at full size

Multi RS 48/6000/100-50 230V - high-frequency inverter/charger 48 V, 6 kVA

Multi RS 48/6000/100-50 230V is a lightweight 48 V, 6 kVA high-frequency inverter/charger for stationary and mobile applications, the variant of the Multi RS Solar without integrated solar chargers. It supports Dynamic ESS, can be combined with another solar inverter, and all parameters are monitored on the built-in display or in the VictronConnect app.

Key features:

  • Battery voltage: 48 V (38-62 V)
  • Rated power: 6000 VA at 25 °C, 4500 W at 40 °C
  • Operating modes: backup, off-grid and generator
  • Charging current: 88 A
  • Transfer relay: 50 A
  • Connectivity: Bluetooth, VE.Direct, VE.Can

The Multi RS 48/6000 is a lightweight 48 V/6 kVA high-frequency inverter/charger, suitable for both stationary and mobile applications. It is the variant of the Multi RS Solar without the solar component and does not include integrated solar charge controllers.

In stationary applications it supports the Dynamic ESS function and gives you the flexibility to pair it with a solar inverter of a different type or power. It can also be used as a direct grid connection without batteries, so you can start simply and add storage later.

In mobile applications, the Multi RS offers a lightweight solution that keeps the batteries fully charged and, when there is surplus energy, can feed it back into the grid.

Monitor all parameters through the built-in display or the VictronConnect app, which also provides historical trend data, fast firmware updates and simple configuration tools. Connect it to a Cerbo GX for advanced ESS functions, including zero-export to prevent feed-in to the grid and backup mode to supply critical loads during power outages.

Technical specifications

PowerControlYes
PowerAssistYes
Parallel operationNu
Three-phase operationYes
Number of AC inputs1
Transfer switch rated current50 A
Nominal battery voltage48 V
DC input voltage range38 … 62 V
AC output voltage230 V
Maximum continuous inverter current25 A
Frequency50
Continuous output power at 25 °C (VA)6000 VA
Continuous output power at 25 °C (W) - A4600 W
Continuous output power at 25 °C (W) - B5200 W
Continuous output power at 40 °C4500 W
Continuous output power at 65 °C3000 W
Peak power (3 s)9000 W
Peak power (4 min)7000 W
Short-circuit current45 A
Maximum efficiency96.5 %
No-load consumption20 W
Shutdown on low battery37.2 V
Restart after low battery43.6 V
Charging voltage range36 … 60 V
Charge voltage in absorption57.6 V
Float charge voltage55.2 V
Maximum battery charge current88 A
Battery temperature sensorIncluded
Battery voltage sensing (voltage sense)Yes
Programmable relayDC rating: 4A up to 35VDC and 1A up to 70VDC
ProtectionsOutput short circuit, Overload, High battery voltage, Low battery voltage, Over-temperature, AC voltage at inverter output
Communication portVE.Direct, VE.Can, Bluetooth
BluetoothDa, -4dBm, 2402 - 2480 MHz
General-purpose communication portDa, 2x
Remote on/offYes
Fully programmable portsYes
Operating temperature range-40 … 65 °C
Fan-assisted coolingYes
Maximum altitude2000 m
Maximum humidity95 %
Maximum AC input current50 A
AC input voltage range187 … 265 VAC
AC input frequency range45 … 65 Hz
Pollution degree2
Auxiliary outputYes
Number of AC outputs2
AC connection terminalsScrew terminals 10 mm² (8 AWG)
Battery connectionM8 bolts
ColourBlue (RAL 5012) and black (RAL 9017)
MaterialSteel
Ingress protectionIP21
Weight11.2 kg
Height462 mm
Width425 mm
Depth127 mm
SafetyEN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1, EN-IEC 62109-2, IEC 62040, IEC 62477
Emission and immunityEN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3

Data sheet

Reference
PMR482604000
EAN13
8719076075189
Brand
Victron Energy
Product type
Inverter/charger
Inverter type
Inverter/charger
Phases
Single-phase
Power class
3.5-6 kW
Continuous output power (VA, 25 °C)
6000 VA
Continuous output power (W, 25 °C)
5200 W
Peak power
9000 W
Maximum efficiency
96.5 %
Zero-load power
20 W
Output waveform
Pure sine wave
Battery voltage
48 V
DC input voltage range
38-62 V
Max. charge current
88 A
AC output voltage
230 V
Output frequency
50 Hz
AC input voltage range
187-265 V
Max. AC input current
50 A
Parallel operation
No
Communication interfaces
Bluetooth
VE.Can
VE.Direct
Programmable relay
Yes
Protections
Output short-circuit, overload, overtemperature, high battery voltage, low battery voltage, AC voltage on output
Dimensions (H x W x D)
462 x 425 x 127 mm
Weight
11.2 kg
Ingress protection (IP)
IP21
Operating temperature
-40 ... 65 °C
Max. relative humidity
95 %
Colour
Blue and black
Material
Steel
Standards and compliance
EN-IEC 60335-1, EN 55014-1, EN 55014-2, EN-IEC 61000-3-2

We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the attached datasheet.
