  • -15%
Inverter Victron Energy Phoenix Compact 12/2000 VE.Bus
  • Inverter Victron Energy Phoenix Compact 12/2000 VE.Bus
  • Inverter Victron Energy Phoenix Compact 12/2000 VE.Bus

Inverter Victron Energy Phoenix Compact 12/2000 VE.Bus

€810 Save €122
€688 Tax included

€573 Tax excluded

The Phoenix Compact 12/2000 VE.Bus is a high-efficiency pure sine-wave inverter with SinusMax technology, designed for professional use. 12 V battery, continuous power 2000 VA (1600 W), peak power 4000 W, maximum efficiency 92%, VE.Bus port, parallel and three-phase operation.

Reference CIN122200000

Victron Energy commercial warranty: 5 years for defects in materials and workmanship, handled through us as the seller. In addition to the legal guarantee. Conditions

Your legal guarantee rights

Legal guarantee

EU harmonised notice on the legal guarantee of conformity

More information: europa.eu/youreurope/guarantees
Open the notice at full size

Phoenix Compact 12/2000 VE.Bus - Sine-wave inverter 12 V, 2000 VA

Phoenix Compact 12/2000 VE.Bus is a pure sine-wave inverter with a continuous power of 2000 VA (1600 W) at a battery voltage of 12 V. It uses SinusMax technology and is intended for professional use.

Key features:

  • Continuous power: 2000 VA / 1600 W
  • Peak power: 4000 W
  • Battery voltage: 12 V
  • Maximum efficiency: 92%
  • Communication port: VE.Bus
  • Dimensions: 520 x 255 x 125 mm
  • Weight: 12 kg

The design criteria focus on an inverter with a sine-wave output and optimum efficiency, with no compromise on performance. Thanks to HF hybrid technology, the product is compact, light and highly reliable. SinusMax technology allows starting at full load, so the inverter handles demanding loads well, such as cooling compressors or electric motors.

Up to 6 inverters can operate in parallel for a higher output power; three-phase operation is also possible. For an automatic transfer switch, the MultiPlus inverter/charger is recommended, with a transfer time of less than 20 milliseconds. Through the VE.Bus port and the MK3-USB interface, with VictronConnect or VEConfigure software, the output voltage and frequency, the over- and undervoltage thresholds and the programmable relay can be customised. The inverter can also be connected to a GX device (for example Cerbo GX) for monitoring and control.

Technical specifications

Nominal battery voltage12 V
DC input voltage range9.5 … 17 V
AC output voltage230 V
Frequency selection50Hz
Continuous output power at 25 °C (VA)2000 VA
Continuous output power at 25 °C (W)1600 W
Continuous output power at 40 °C1450 W
Continuous output power at 65 °C1000 W
Peak power4000 W
Maximum efficiency92%
No-load consumption9 W
No-load consumption in AES mode7 W
No-load consumption in search mode3 W
Programmable relayAC ratings: 230V / 4A, DC ratings: 4A up to 35VDC and 1A up to 60VDC
Remote on/off terminalYes
Communication portVE.Bus
Fully programmableYes
Parallel and three-phase operationYes
ProtectionsOutput short circuit, overload, battery voltage too high, battery voltage too low, over-temperature, AC voltage at the inverter output, excessive DC ripple
Operating temperature range-40 … 65 °C
CoolingYes
Maximum humidity95%
Battery connectionM8 screws
AC connectionSpring clamp
Remote control terminal2-pole screw terminal
Relay terminal3-pole screw terminal
ColourBlue (RAL 5012)
MaterialAluminium
Protection ratingIP21
Weight12 kg
Height520 mm
Width255 mm
Depth125 mm
SafetyEN-IEC 60335-1
EMCEN 55014-1, EN 55014-2

Data sheet

Reference
CIN122200000
Brand
Victron Energy
Product type
Inverter
Inverter type
Inverter (no charger)
Phases
Single-phase
Power class
1-2 kW
Continuous output power (VA, 25 °C)
2000 VA
Continuous output power (W, 25 °C)
1600 W
Peak power
4000 W
Maximum efficiency
92 %
Zero-load power
9 W
Output waveform
Pure sine wave
Battery voltage
12 V
DC input voltage range
9.5-17 V
AC output voltage
230 V
Output frequency
50 Hz
Parallel operation
Yes
Communication interfaces
VE.Bus
Programmable relay
Yes
Protections
Output short-circuit, overload, overtemperature, high battery voltage, low battery voltage, excessive DC ripple, AC voltage on output
Dimensions (H x W x D)
520 x 255 x 125 mm
Weight
12 kg
Ingress protection (IP)
IP21
Operating temperature
-40 ... 65 °C
Max. relative humidity
95 %
Colour
Blue
Material
Aluminium
Standards and compliance
EN-IEC 60335-1, EN 55014-1, EN 55014-2

We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the attached datasheet.
