€259 Tax excluded
Phoenix 24/1200 230V VE.Direct IEC is a 1200 VA inverter (1000 W continuous at 25 °C) that powers 230V AC domestic equipment from 24V leisure or automotive batteries. The VE.Direct port allows full configuration and monitoring, while ECO mode reduces no-load consumption to 1.5 W. The output socket is of IEC-320 type.
Victron Energy commercial warranty: 5 years for defects in materials and workmanship, handled through us as the seller. In addition to the legal guarantee. Conditions
Phoenix 24/1200 230V VE.Direct IEC is a 1200 VA inverter (1000 W continuous at 25 °C) that powers 230V AC domestic equipment from 24V leisure or automotive batteries. The VE.Direct port allows full configuration and monitoring, while ECO mode reduces no-load consumption to 1.5 W. The output socket is of IEC-320 type.
Inverters allow you to power domestic equipment - requiring 230V/120V AC - using 'leisure' or 'automotive' batteries rated at 12V, 24V or 48V DC.
| Nominal battery voltage | 24 V |
|---|---|
| Continuous output power at 25 °C (VA) | 1200 VA |
| Continuous output power at 25 °C (W) | 1000 W |
| Continuous output power at 40 °C | 850 W |
| Peak power | 2200 W |
| AC output voltage | 230 V |
| Frequency | 50 Hz |
| DC input voltage range | 18.4 … 34 V |
| DC low shutdown | 18.6 V |
| DC low restart and alarm | 21.8 V |
| Dynamic low DC shutdown | Yes |
| Battery charged detection voltage | 28 V |
| Maximum efficiency | 91 % |
| Zero load power | 11 W |
| Zero load power in ECO mode | 1.5 W |
| ECO mode retry interval | 2.5 s |
| ECO mode stop/start power setting | Adjustable |
| Remote on/off terminal | Yes |
| Communication port | VE.Direct |
| Fully programmable | Yes |
| Protections | Excessive DC ripple, High battery voltage, Low battery voltage, Output short-circuit, Over temperature, Overload |
| Operating temperature range | -40 … 65 °C |
| Maximum humidity | 95 % |
| Power derating | 1.25 % |
| AC outlet socket | IEC-320 (male plug included) |
| Battery connection terminals | Screw terminals 25 mm² (4 AWG) |
| Remote control terminal | Screw terminal two pole |
| Colour | Blue (RAL 5012) |
| Material | Steel chassis and plastic cover |
| Protection category | IP21 |
| Weight | 7.4 kg |
| Height | 117 mm |
| Width | 232 mm |
| Depth | 327 mm |
| Safety | EN-IEC 60335-1, EN-IEC 62109-1 |
| EMC | EN 55014-1, EN 55014-2, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3 |
| Automotive directive | ECE R10-4 |
We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the attached datasheet.
