Inverter 12/1600 230V Smart Victron Energy
  • Inverter 12/1600 230V Smart Victron Energy
  • Inverter 12/1600 230V Smart Victron Energy
  • Inverter 12/1600 230V Smart Victron Energy
  • Inverter 12/1600 230V Smart Victron Energy

Inverter 12/1600 230V Smart Victron Energy

€688 Save €104
€584 Tax included

€487 Tax excluded

The Inverter 12/1600 230V Smart is a 1,600 VA inverter for 12 V systems, with a full metal casing and a toroidal transformer that provides high peak power and a high-quality sine wave. Built-in Bluetooth allows alarms, relay, voltage cut-off, output voltage, frequency and ECO mode to be configured in VictronConnect. It is short-circuit proof and protected against overheating.

Reference PIN122161000

Victron Energy commercial warranty: 5 years for defects in materials and workmanship, handled through us as the seller. In addition to the legal guarantee. Conditions

Your legal guarantee rights

Legal guarantee

EU harmonised notice on the legal guarantee of conformity

More information: europa.eu/youreurope/guarantees
Open the notice at full size

Inverter 12/1600 230V Smart - Inverter with Bluetooth 12 V, 1600 VA

The Inverter 12/1600 230V Smart is a 1,600 VA inverter for 12 V systems, with a full metal casing and a toroidal transformer that provides high peak power and a high-quality sine wave. Built-in Bluetooth allows alarms, relay, voltage cut-off, output voltage, frequency and ECO mode to be configured in VictronConnect. It is short-circuit proof and protected against overheating.

Main features:

  • Battery voltage: 12 V (9.3-17 V)
  • Continuous power: 1,600 VA / 1,300 W at 25 °C
  • Peak power: 3,000 W, for LED converters, halogen lamps, power tools
  • AC output: 230 V, 50 or 60 Hz, adjustable 210-245 V
  • Maximum efficiency: 92 %
  • Connectivity: Bluetooth, VE.Direct, programmable alarm relay

The Inverter Smart is an efficient and reliable inverter. Built on our proven and field tested inverter platform, it now comes with a new slimmer design and full metal casing. Models are available in 1600VA, 2000VA, 3000VA and 5000VA for 12, 24 or 48V systems.

It’s powerful enough to supply most common plug in appliances in your car, boat, caravan or home. A toroidal transformer provides a high peak power surge capacity, stable voltage, frequency and high quality sine-wave.

Installation is simpler than ever before with terminals now more accessible for the installer, enabling a more professional finish.

Bluetooth is built-in, and makes setting up your high power inverter easier than ever before.
Configure alarms, alarm relay, voltage cut-off, output voltage, frequency, eco-mode and more, all from within VictronConnect.

Technical specifications

Nominal battery voltage12 V
DC input voltage range9.3 … 17 V
AC output voltage230 V
Frequency50Hz or 60Hz
Continuous output power at 25 °C (VA)1600 VA
Continuous output power at 25 °C (W)1300 W
Continuous output power at 40 °C1200 W
Continuous output power at 65 °C800 W
Peak power3000 W
Dynamic low DC shutdownYes
Maximum efficiency92 %
Zero load power8 W
Zero load power in ECO mode0.6 W
ECO mode stop/start power settingAdjustable
Parallel and 3-phase operationNo
Remote on/off terminalYes
Programmable relayAC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC
BluetoothYes
Communication portBluetooth, VE.Direct
Fully programmableYes
ProtectionsOutput short-circuit, Overload, High battery voltage, Low battery voltage, Over temperature, AC voltage on inverter output, Excessive DC ripple
Operating temperature range-40 … 65 °C
Maximum humidity95 %
AC connectionScrew terminals
Battery connectionM8 bolts
Remote control terminalScrew terminal two pole
Relay terminalScrew terminal 3-pole
ColourBlue (RAL 5012) and Black (RAL 9017)
MaterialSteel
Protection categoryIP21
Weight12 kg
Height482 mm
Width219 mm
Depth125 mm
SafetyEN-IEC 60335-1
Emission and immunityEN 55014-1, EN 55014-2, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3
Automotive directiveECE R10-5

Data sheet

Reference
PIN122161000
EAN13
8719076057505
Brand
Victron Energy
Product type
Inverter
Inverter type
Inverter (no charger)
Phases
Single-phase
Power class
1-2 kW
Continuous output power (VA, 25 °C)
1600 VA
Continuous output power (W, 25 °C)
1300 W
Peak power
3000 W
Maximum efficiency
92 %
Zero-load power
8 W
Output waveform
Pure sine wave
Battery voltage
12 V
DC input voltage range
9.3-17 V
AC output voltage
230 V
Output frequency
50/60 Hz
Parallel operation
No
Communication interfaces
Bluetooth
VE.Direct
Programmable relay
Yes
Protections
Output short-circuit, overload, overtemperature, high battery voltage, low battery voltage, excessive DC ripple, AC voltage on output
Dimensions (H x W x D)
485 x 219 x 125 mm
Weight
12 kg
Ingress protection (IP)
IP21
Operating temperature
-40 ... 65 °C
Max. relative humidity
95 %
Colour
Blue and black
Material
Steel
Standards and compliance
EN-IEC 60335-1, ECE R10-5, EN 55014-1, EN 55014-2

We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the attached datasheet.
