€107 Tax excluded
The Victron Phoenix Inverter 48/375 VE.Direct Schuko is a sine-wave inverter for 48 V batteries, with a continuous output power of 375 VA (300 W) at 25 °C, a peak power of 700 W, a maximum efficiency of 90 % and a 230 V output. It has a VE.Direct port, remote on/off control and an ECO mode.
Victron Energy commercial warranty: 5 years for defects in materials and workmanship, handled through us as the seller. In addition to the legal guarantee. Conditions
Victron Phoenix Inverter 48/375 VE.Direct Schuko is a sine-wave inverter with a continuous output power of 375 VA (300 W) at 25 °C, for 48 V batteries and a 230 V output, with a VE.Direct port. It powers household appliances that need 230 V AC from leisure or vehicle batteries.
The VE.Direct port can be connected to a computer (a VE.Direct to USB interface cable is required) or to Apple and Android smartphones, tablets, MacBooks and other devices (a VE.Direct Bluetooth Smart dongle is required). The inverter is fully configurable: trigger and reset levels of the low battery voltage alarm, shutdown and restart levels, dynamic cut-off (load-dependent cut-off level), output voltage 210-245 V, ECO mode and detection level for ECO mode. Input and output voltage, load percentage and alarms are monitored.
The high starting power makes it possible to supply loads such as power supplies for LED lamps, halogen lamps or power tools. In ECO mode, the inverter switches to standby when the load falls below a preset value (minimum load 15 W) and switches on for a short time, by default every 2.5 seconds (adjustable); if the load exceeds the preset level, it stays on. A remote on/off switch can be connected to the two-pole connector, with no special tools needed for installation.
| Nominal battery voltage | 48 V |
|---|---|
| Continuous output power at 25 °C (VA) | 375 VA |
| Continuous output power at 25 °C (W) | 300 W |
| Continuous output power at 40 °C | 260 W |
| Peak power | 700 W |
| AC output voltage | 230 V |
| Frequency | 50 Hz |
| DC input voltage range | 36.8 … 62 V |
| Low DC voltage shutdown | 37.2 V |
| Low DC voltage restart and alarm | 43.6 V |
| Dynamic low DC voltage shutdown | Yes |
| Charged battery detection voltage | 56 V |
| Maximum efficiency | 90 % |
| No-load consumption | 8.5 W |
| No-load consumption in ECO mode | 2.6 W |
| Retry interval in ECO mode | 2.5 s |
| Power off/on setting in ECO mode | Adjustable |
| Remote on/off terminal | Yes |
| Communication port | VE.Direct |
| Fully programmable | Yes |
| Protections | Excessive DC ripple, high battery voltage, low battery voltage, output short circuit, overtemperature, overload |
| Operating temperature range | -40 … 65 °C |
| Maximum humidity | 95 % |
| Power derating | 1.25 % |
| AC output socket | Schuko (CEE 7/4) |
| Battery connection terminals | Screw terminals 10 mm² (8 AWG) |
| Remote control terminal | Two-pole screw terminal |
| Colour | Blue (RAL 5012) |
| Material | Steel chassis and plastic cover |
| Protection rating | IP21 |
| Weight | 3 kg |
| Height | 86 mm |
| Width | 165 mm |
| Depth | 260 mm |
| Safety | EN-IEC 60335-1, EN-IEC 62109-1 |
| EMC | EN 55014-1, EN 55014-2, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3 |
| Automotive directive | ECE R10-4 |
We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the attached datasheet.
Compatibility is calculated automatically from the manufacturers’ technical data and is for information only. For complex systems, we recommend having the configuration checked by a consultant before ordering. Details in the Terms and conditions
