The Victron Phoenix Inverter 48/250 VE.Direct Schuko is a sine wave inverter for 48 V batteries, with 250 VA (200 W) continuous power at 25 °C, 400 W peak power, 88 % maximum efficiency and a 230 V output. It has a VE.Direct port, remote on/off control and ECO mode.
Victron Energy commercial warranty: 5 years for defects in materials and workmanship, handled through us as the seller. In addition to the legal guarantee. Conditions
Victron Phoenix Inverter 48/250 VE.Direct Schuko is a sine wave inverter with 250 VA (200 W) continuous power at 25 °C, for 48 V batteries and a 230 V output, with a VE.Direct port. It allows household appliances that require 230 V AC to be powered from leisure or automotive batteries.
The VE.Direct port can be connected to a computer (a VE.Direct to USB interface cable is required) or to Apple and Android smartphones, tablets, MacBooks and other devices (a VE.Direct Bluetooth Smart dongle is required). The inverter is fully configurable: trigger and reset levels of the low battery voltage alarm, cut-off and restart levels, dynamic cut-off (load-dependent cut-off level), output voltage 210-245 V, ECO mode and the detection level for ECO mode. Input and output voltage, load percentage and alarms are monitored.
The high starting power allows it to supply loads such as power converters for LED lamps, halogen lamps or power tools. In ECO mode, the inverter switches to standby when the load falls below a preset value (minimum load 15 W) and switches on for a short period, by default every 2.5 seconds (adjustable); if the load exceeds the preset level, it stays on. A remote on/off switch can be connected to the two-pole connector, with no special tools needed for installation.
| Nominal battery voltage | 48 V |
|---|---|
| Continuous output power at 25 °C (VA) | 250 VA |
| Continuous output power at 25 °C (W) | 200 W |
| Continuous output power at 40 °C | 175 W |
| Peak power | 400 W |
| AC output voltage | 230 V |
| Frequency | 50 Hz |
| DC input voltage range | 36.8 … 62 V |
| Low DC voltage shut-down | 37.2 V |
| Restart and alarm at low DC voltage | 43.6 V |
| Dynamic cut-off at low DC voltage | Yes |
| Charged-battery detection voltage | 56 V |
| Maximum efficiency | 88 % |
| No-load power consumption | 7.9 W |
| No-load power consumption in ECO mode | 2.5 W |
| Retry interval in ECO mode | 2.5 s |
| Power shut-down/wake-up setting in ECO mode | Adjustable |
| Remote on/off terminal | Yes |
| Communication port | VE.Direct |
| Fully programmable | Yes |
| Protections | Excessive DC ripple, High battery voltage, Low battery voltage, Output short circuit, Over-temperature, Overload |
| Operating temperature range | -40 … 65 °C |
| Maximum humidity | 95 % |
| Power derating | 1.25 % |
| Remote control terminal | Two-pole screw terminal |
| Colour | Blue (RAL 5012) |
| Material | Steel chassis and plastic cover |
| Protection rating | IP21 |
| Weight | 2.4 kg |
| Height | 86 mm |
| Width | 165 mm |
| Depth | 260 mm |
| Safety | EN-IEC 60335-1, EN-IEC 62109-1 |
| EMC | EN 55014-1, EN 55014-2, EN-IEC 61000-6-1, EN-IEC 61000-6-2, EN-IEC 61000-6-3 |
| Automotive directive | ECE R10-4 |
