€688 Tax excluded
The Deye SUN-6K-G is a single-phase grid-tied inverter of 6 kW, without battery, with 2 MPPT in the 70-500 V range and a maximum efficiency of 97.5%. It accepts a 7800 W input from the solar panels, starts the MPPT from 80 V, has an IP65 protection rating and a Wi-Fi module with a free app.
Deye SUN-6K-G is a single-phase grid-tied inverter of 6 kW, without battery, with 2 MPPT and a maximum efficiency of 97.5%. It transforms the energy of the photovoltaic panels into alternating current for the grid, starts the MPPT from 80 V and includes a Wi-Fi module with a free app for monitoring.
The inverter has no battery and feeds the energy produced by the photovoltaic panels into the grid. The input capacity from the panels is 7800 W, and the MPPT starts from 80 V.
The product has a display, an RS485 communication port and an included Wi-Fi module with a free app for monitoring.
| Product code | SUN-6K-G |
|---|---|
| Product type | Inverter |
| Inverter type | Grid-tied (without battery) |
| Phases | Single-phase |
| Power class | 3.5-6 kW |
| Continuous output power (W, 25 °C) | 6000 W |
| Maximum efficiency | 97.5 % |
| Output waveform | Pure sine wave |
| Battery voltage | No battery |
| Maximum panel input voltage | 550 V |
| Number of MPPTs | 2 |
| MPPT voltage range | 70-500 V |
| AC output voltage | 220/230 V |
| Output frequency | 50/60 Hz |
| Communication interfaces | Wi-Fi, Ethernet, RS485 |
| Dimensions (height x width x depth) | 323 x 330 x 190 mm |
| Weight | 7.5 kg |
| Protection rating (IP) | IP65 |
| Operating temperature | -25 ... 65 °C |
| Maximum relative humidity | 100 % |
| Standards and compliance | IEC/EN 62109-1, IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-2 |
| Maximum panel input power | 7800 W |
| MPPT start voltage | 80 V |
| Display | Yes |
| Wi-Fi module | Included, with free app |
We took these technical data from the manufacturer’s datasheet; transcription errors are possible. For 100% accuracy, please consult the attached datasheet.
Compatibility is calculated automatically from the manufacturers’ technical data and is for information only. For complex systems, we recommend having the configuration checked by a consultant before ordering. Details in the Terms and conditions
