12 kW Hybrid-Wechselrichter Pylontech Force-H3X, dreiphasig, HV, FH3X-12K-HY-3P

Name: 12 kW Hybrid-Wechselrichter Pylontech Force-H3X, dreiphasig, HV, FH3X-12K-HY-3P
Brand: Pylontech
SKU: FH3X-12K-HY-3P
Price: 2413.00 EUR
Availability: InStock

2.413 € Steuern inklusive

2.011 € Ohne Steuern

FH3X-12K-HY-3P is a 12 kW three-phase hybrid inverter with 3 MPPT (200-850 V) and built-in BMS, mounted on 2-7 FH10050 battery modules (10.24-35.84 kWh). It has a maximum efficiency of 98%, a maximum charge and discharge current of 50 A, a back-up output with switchover in 10 ms or less, and Wi-Fi and Bluetooth communication.

Referenz FH3X-12K-HY-3P

Ihre Rechte aus der gesetzlichen Gewährleistung

FH3X-12K-HY-3P - Three-phase hybrid inverter 12 kW for HV battery modules

FH3X-12K-HY-3P is the all-in-one controller of the Pylontech Force-H3X system: a 12 kW three-phase hybrid inverter with built-in MPPT and BMS, mounted directly on 2-7 FH10050 battery modules (10.24-35.84 kWh) to form a complete solar storage system, with no extra junction box or switch. The FH10050 modules are not included and are added separately.

Main features:

Rated power: 12 kW
PV input: 3 MPPT, 200-850 V, maximum 19.2 kW
Battery: 2-7 FH10050 modules, 10.24-35.84 kWh
Battery current: 50 A charge and discharge
Maximum efficiency: 98%
Back-up output: 12000 VA, switchover in at most 10 ms
Communication: Wi-Fi and Bluetooth

The controller contains the inverter, the MPPT trackers and the battery management system (BMS). It is installed on 2-7 FH10050 battery modules of 102.4 V and 5.12 kWh (system capacity 10.24-35.84 kWh) and does not use the FC1000 controller of the Force-H3 system. With 2 modules charging can reach 10 kW and discharging 10 kW; with 3-7 modules charging can reach 15 kW and discharging 12 kW.

The PV input has 3 MPPT with one string each, an MPPT range of 200-850 V (full load 280-850 V), a start-up voltage of 200 V, a maximum input voltage of 1000 V, a maximum current of 20 A and a short-circuit current of 30 A per MPPT; the maximum PV power is 19.2 kW. The grid is 3/N/PE, 400 V, 50/60 Hz, with a nominal current to the grid of 17.4 A and a maximum current from the grid of 26.1 A, and the three-phase output accepts 100% unbalanced loads. The back-up output delivers 12000 VA, with a peak of 18000 VA for 60 s, and the changeover between grid and back-up takes at most 10 ms.

The controller box contains the base, the anti-tipping and module brackets, the AC, PV and RJ45 connectors, one energy meter and the mounting accessories; the battery modules are packed separately. The controller has natural cooling, a transformerless topology, a noise level below 30 dB at 1 m, a night-time consumption below 15 W, an LED display, an installed emergency power off (EPO) button and Wi-Fi and Bluetooth communication. It operates at -10...55 °C (power is reduced above 45 °C), at 0-100% humidity, and power is reduced above 2000 m altitude. The user manual states parallel operation of up to 6 units.

Technical specifications

Type	Three-phase all-in-one hybrid inverter, controller with built-in BMS
Battery module model	FH10050
Number of battery modules	2 / 3 / 4 / 5 / 6 / 7
System nominal capacity	10.24 / 15.36 / 20.48 / 25.6 / 30.72 / 35.84 kWh
System nominal power	12 kW
Maximum PV power	19.2 kW
Maximum PV input voltage	1000 V
Start-up voltage	200 V
MPPT voltage range	200-850 V
MPPT full-load voltage range	280-850 V
Number of MPPT	3
Number of PV strings per MPPT	1
Maximum input current per MPPT	20 A
Short-circuit current per MPPT	30 A
PV surge protection	Type II
Maximum continuous charge/discharge current	50 A
Maximum charging power with 2 modules	10 kW
Maximum discharging power with 2 modules	10 kW
Maximum charging power with 3-7 modules	15 kW
Maximum discharging power with 3-7 modules	12 kW
Nominal grid voltage	3/N/PE, 400 V
Nominal grid frequency	50/60 Hz
Nominal continuous current to the grid	17.4 A
Nominal active power to the grid	12000 W
Maximum apparent power to the grid	12000 VA
Maximum continuous current from the grid	26.1 A
Nominal active power from the grid	18000 W
Maximum apparent power from the grid	18000 VA
Power factor range	-0.8...+0.8
Current harmonic distortion (THDi)	< 3 %
Nominal voltage (back-up)	3/N/PE, 400 V
Nominal output frequency (back-up)	50/60 Hz
Maximum continuous current (back-up)	17.4 A
Maximum apparent power (back-up)	12000 VA
Peak off-grid power (60 s)	18000 VA
Grid / back-up switching time	≤ 10 ms
Voltage harmonic distortion (THDv)	< 3 %
Maximum efficiency	98 %
European efficiency	97.5 %
Protections	Anti-islanding, AFCI 2.0 (IEC 63027), insulation resistance monitoring, residual current monitoring, output overcurrent, short-circuit and overvoltage protection, DC switch, DC reverse-polarity protection, PV overvoltage protection, DC/AC surge protection type II
Complete system dimensions, W x H x D (2-7 modules, without base)	540 x 835 / 1005 / 1175 / 1345 / 1515 / 1685 x 350 mm
Complete system weight (2-7 modules, without base)	121 / 160 / 199 / 238 / 277 / 316 kg
Topology	Transformerless
Operating temperature	-10...55 °C (power is reduced above 45 °C)
Operating relative humidity	0-100 %
Altitude	Power is reduced above 2000 m
Noise level (1 m)	< 30 dB
Protective class	I
Overvoltage category	DC II / AC III
Ingress protection	IP65
Salt spray resistance	C5-M
Cooling	Natural
Standby consumption (night)	< 15 W
Communication	Wi-Fi, Bluetooth
Display	LED
Emergency power off (EPO)	Installed
Parallel operation	Up to 6 units
Standards and compliance	VDE-AR-N 4105, EN 50549-1, EN 50549-10, IEC 62109-1, IEC 62109-2, IEC 62619, IEC 62477-1, UN 38.3, VDE-AR-E 2510-50, CEI 0-21, G98, G99

Datenblatt

Referenz: FH3X-12K-HY-3P
MPN: FH3X-12K-HY-3P
Produkttyp: Wechselrichter
Wechselrichtertyp: Hybrid (mit integriertem MPPT)
Phasen: Dreiphasig
Leistungsklasse: 10-20 kW
Dauerleistung (W, 25 °C): 12000 W
Spitzenleistung: 18000 VA, 60 s
Maximaler Wirkungsgrad: 98 %
Leerlaufverbrauch: unter 15 W
Batteriespannung: HV (Hochvolt)
Max. Ladestrom: 50 A
Max. PV-Eingangsspannung: 1000 V
Max. PV-Kurzschlussstrom: 30 A
Anzahl MPPT-Tracker: 3
MPPT-Spannungsbereich: 200-850 V
AC-Ausgangsspannung: 400 V
Ausgangsfrequenz: 50/60 Hz
Max. AC-Eingangsstrom: 26,1 A
Parallelbetrieb: Ja
Kommunikationsschnittstellen: Bluetooth
WLAN
Schutzfunktionen: Inselnetzerkennung, AFCI 2.0 (IEC 63027), Isolationswiderstandsüberwachung, Fehlerstromüberwachung, Ausgangsschutz gegen Überstrom, Kurzschluss und Überspannung, DC-Schalter, Verpolungsschutz DC, PV-Überspannungsschutz, DC/AC-Überspannungsschutz Typ II
Abmessungen (H x B x T): 495 x 540 x 350 mm
Gewicht: 43 kg
Schutzart (IP): IP65
Betriebstemperatur: -10 ... 55 °C
Max. relative Luftfeuchtigkeit: 100 %
Normen und Konformität: VDE-AR-N 4105, EN 50549-1, EN 50549-10, IEC 62109-1, IEC 62109-2, IEC 62619, IEC 62477-1, UN 38.3, VDE-AR-E 2510-50, CEI 0-21, G98, G99

Diese technischen Daten wurden von uns aus dem Datenblatt des Herstellers übernommen und können Übertragungsfehler enthalten. Für 100 % Genauigkeit sehen Sie bitte im beigefügten Datenblatt nach.

Kompatibilität

Batteriemodul Pylontech Force-H3 5,12 kWh, 102,4 V HV, FH10050

5,12 kWh 102,4 V mind. 2 Module

1.231 €

Die Kompatibilität wird automatisch aus den technischen Daten der Hersteller berechnet und dient nur zur Information. Bei komplexen Anlagen empfehlen wir, die Konfiguration vor der Bestellung von einem Berater prüfen zu lassen. Details in den AGB
