Lynx Class-T Power In (M10) Victron Energy

Lynx Class-T Power In (M10) - Class-T fused input module for lithium batteries

Lynx Class-T Power In (M10) is a distribution module that connects and fuses up to two strings of lithium batteries. It features positive and negative busbars, connections for two Class-T fuses and a connection for grounding the DC system, and integrates with all other M10 Lynx products.

Main features:

• Battery strings: up to 2 lithium battery strings
• Class-T fuses: 225, 250, 350 or 400 A, sold separately
• Rated current: 1,000 A
• Voltage: 9-60 V
• Busbar connections: M10, tinned copper
• Protection rating: IP22

The Lynx Class-T Power In connects and fuses up to two strings of Lithium batteries. It features a positive and negative busbar, and connections for two Class-T fuses as well as a connection to ground the DC system. The Class T-fuses, available in 225A, 250A, 350A and 400A, must be purchased separately.

For installations using three or more strings of Lithium batteries, use multiple Lynx Class-T modules. As a core component of the Lynx Distribution system, the Lynx Class-T seamlessly integrates with all other M10 Lynx products.

Technical specifications
