Orion 24/12-30 DC-DC converter IP20 Victron Energy

Orion 24/12-30 IP20 - DC-DC converter 24 V to 12 V

Orion 24/12-30 IP20 is a non-isolated DC-DC converter for powering 12 V loads from a 24 V system, delivering 30 A continuous with an output adjustable between 10 and 15 V. It can also charge a 12 V starter or accessory battery, and up to five units can be connected in parallel.

Main features:

• Input voltage: 18-35 V
• Output voltage: 10-15 V, adjustable (factory set 13.2 V)
• Output current: 30 A continuous, 40 A maximum
• Maximum efficiency: 96 %
• Parallel connection: up to 5 units
• Remote on/off: via low-power switch or engine run/stop switch

Remote on/off connector
The remote on/off eliminates the need for a high current switch in the input wiring. The remote on-off can be operated with a low power switch or by the engine run/stop switch (see manual).

All models with adjustable output can also be used as a battery charger
For example to charge a 12 Volt starter or accessory battery in an otherwise 24V system.

All models with adjustable output can be paralleled to increase output current
Up to five units can be connected in parallel.

Technical specifications
