Huawei Three-Phase Back-Up System


Backup Box-B1 is a three-phase backup solution for photovoltaic systems developed by Huawei.


Huawei Three-Phase Back-Up System
When a power outage occurs, the Backup Box directs the energy generated by the photovoltaic panels and stored in the batteries to a group of priority consumers. After the power grid is restored, the energy is redirected to all consumers. Backup Box-B1 is a high-quality and robust module, with protection guaranteed by the IP65 standard against water and dust, and with an optimal operating temperature between -20°C and +45°C.

Battery type: LifePo4
Power phase: three-phase
Maximum output current: 15.2 A
Compatible inverters: SUN2000-3/4/5 /6/8/10KTL-M1
Protection degree: IP65
Operating temperature: -20°C - +45°C
Dimensions: 40.0 × 35.0 × 13.0 cm
Weight: 11 Kg

Specific References


Huawei Backup Box B1

Download (214.99k)
